Trisole shade structure up to 11.8 x 3.75 m

Trisole is a self-supporting shade structure with a steel frame. Sizes run from 710 x 350 to 1180 x 375 cm, so it shades long, narrow areas. Independent motors drive the awnings. A protective roof sits on top.

frame: steel, cataphoresis treated and powder coated
opening: independent motors
sizes: from 710 x 350 to 1180 x 375 cm
weight: not given in the maker's price list
colours: anthracite, corten, ivory, white, other RAL shades at extra cost
code: TRI7170, TRI7175, TRI8370, TRI8375, TRI9570, TRI9575, TRI10770, TRI10775, TRI11870, TRI11875

Description

Technical data

frame: steel, cataphoresis treated and powder coated
pillar: 250 x 250 mm
drive: independent motors
stainless steel screws
protective roof
canopy: solution-dyed acrylic
sizes:
- 710 x 350 cm
- 710 x 375 cm
- 830 x 350 cm
- 830 x 375 cm
- 950 x 350 cm
- 950 x 375 cm
- 1070 x 350 cm
- 1070 x 375 cm
- 1180 x 350 cm
- 1180 x 375 cm
height and weight: not given in the maker's price list
mounting: without, base frame 140 x 140 cm, concrete ballast 120 kg (50 x 50 cm), ground socket for concrete or metal plate 125 x 125 cm
number of concrete ballasts: 8 pieces (710 x 350, 710 x 375, 830 x 350, 830 x 375, 950 x 350, 950 x 375 cm), 12 pieces (1070 x 350, 1070 x 375, 1180 x 350, 1180 x 375 cm)
frame colours: anthracite, corten, ivory, white, other RAL shades to order at extra cost
accessories: base cover, LED lighting

ACRYLIC - long lasting
Traditional acrylic is a yarn made from man-made fibres. It is fully synthetic. Its use has grown steadily in recent years because it is versatile and works in every field. The acrylic we use weighs 300 g/m². It is waterproof and treated against mould. Its main strengths are resistance to wear and to weather. This makes it a long-lasting choice if you want a professional, technically sound product.

TEMPOTEST acrylic
As with the other PARA fabrics, the dyed fabric gets a special treatment with Teflon® protection. This protection stops dirt from building up naturally. As a result the fabric repels water and keeps its shape extremely well. We use it for special situations or when you want a guarantee of durability and extra resistance. It comes in a range of colours and has a 5-year guarantee. It also weighs 300 g/m².

PVC - for professionals
PVC canopies keep their shape exceptionally well and last a long time. Other canopy types do not match this. That is why PVC is rightly seen as the canopy for professionals. It suits you if your work needs a 100% guarantee against the weather. The PVC we use weighs 400 g/m². You can clean it easily with water and a neutral detergent.
