Fim base ALU 3

Demountable freestanding base ALU 3 in powder coated aluminium with an adjustable foot, for the Rodi, Ischia, Capri and Rio umbrellas. It is 13 cm high, measures 56 x 108 cm in plan and takes concrete or iron tiles 50 x 50 cm. The price covers 1 base.

code: GBASE004200

colour: silver (SILV), graphite (GRAF) or white (BIAN), state the colour in the order note

weight: 9.8 kg packed

Material: powder coated aluminium, demountable, with adjustable foot.
Colour: silver (SILV), graphite (GRAF) or white (BIAN). For the Rio umbrella graphite and white are available.
Dimensions: height 13 cm, plan 56 x 108 cm.
Ballast for Rodi and Capri: 10 concrete or 10 iron tiles 50 x 50 cm, at least 200 kg.
Ballast for Ischia and Rio: 6 concrete or 6 iron tiles 50 x 50 cm, at least 120 kg.
Ballast tiles: concrete block 50 x 50 x 4 cm (22 kg) or steel plate 50 x 50 x 1 cm (20 kg).
Cover: 2 covers 50 x 50 cm (PCART002600) hide the tiles.
Fits: Rodi, Ischia, Capri and Rio.
The price covers 1 base.
Packaging: 1 package, 9.8 kg, 0.04 m³.

Dimensions

The drawing shows the height and the plan of the base in cm.
