Ocean Master M1 Zero Horizon up to R 3.7 m or 2.9 x 2.9 m

Name: Ocean Master M1 Zero Horizon up to R 3.7 m or 2.9 x 2.9 m
Brand: Tuuci
SKU: OMZ
Price: 2380.00 EUR
Availability: InStock

Tuuci Ocean Master M1 Zero Horizon parasol

Ocean Master M1 Zero Horizon has a canopy with a "zero" vertical profile. You get a lot of shade and keep an open view. You choose from 8 sizes, from 200 x 200 cm to R 370 cm.

frame: mast Ø 38.1 or 51 mm, polished titanium hub
lift: Auto-LOC, EasyDrive crank optional
sizes: square 200 x 200 to 290 x 290 cm, octagon R 245 to R 370 cm
frame colours: Polished Titanium, 8 powder coats, 6 Plantation Aluma-Teak
fabric: Marine MXT level C, Premier PXT level E
code: OMZ

Description

Technical data

frame: mast Ø 38.1 or 51 mm (see sizes)
standard features: market cut profile, polished titanium hub, Triton finial.
sizes:
- OMZ6.5SQ: 200 x 200 cm, square, mast Ø 38.1 mm, minimum anchor weight 41 kg, cover SS3/CS3
- OMZ7.5SQ: 225 x 225 cm, square, mast Ø 38.1 mm, minimum anchor weight 41 kg, cover SS3/CS3
- OMZ8.5SQ: 260 x 260 cm, square, mast Ø 38.1 mm, minimum anchor weight 48 kg, cover SS3/CS3, EasyDrive crank available
- OMZAS9.5SQ: 290 x 290 cm, square, Auto-Scope version, mast Ø 51 mm, minimum anchor weight 64 kg, cover SS4/CS4, EasyDrive crank available
- OMZ8.0OCT: R 245 cm, octagon, mast Ø 38.1 mm, minimum anchor weight 41 kg, cover SS3/CS3
- OMZ10.0OCT: R 300 cm, octagon, mast Ø 38.1 mm, minimum anchor weight 48 kg, cover SS3/CS3
- OMZ11.0OCT: R 340 cm, octagon, mast Ø 38.1 mm, minimum anchor weight 48 kg, cover SS3/CS3
- OMZ12.0OCT: R 370 cm, octagon, mast Ø 51 mm, minimum anchor weight 64 kg, cover SS3/CS3
fabric: all Marine MXT series (level C) are included. Premier PXT (level E) adds 20 % of the size price. The surcharge does not apply to frame colour, lift or lighting. You find the fabric colours on tuuci.com.
frame colours: Polished Titanium (standard). Powder coat, 8 colours (Silver Sand, Glacier White, Sandbar, Oyster, Night Fog, Espresso, Graphite, Black Sea): +€ 190. Plantation Aluma-Teak, 6 finishes (Aspen White, Cypress, Driftwood, Weathered, Natural, Java): +€ 445.
lift: the Auto-LOC marine pulley lift is included. The EasyDrive crank lift costs +€ 190. The sizes list shows where it is available.
lighting and heating: not available for this model.
mounting: Auto-Scope sizes need a 51 mm security sleeve (upcharge on the anchors +€ 70).
ordered separately (accessories):
- protective covers (the code is listed with each size):
  - Custom protective cover CS3: € 510
  - Custom protective cover CS4: € 510
  - Standard protective cover, dark grey polyester SS3: € 155
  - Standard protective cover, dark grey polyester SS4: € 155
- anchors and mounts:
  - Aluma-Crete round anchor with wheels (ACFW): from € 505
  - Aluma-Crete round anchor with lift handles (ACF): from € 820
  - G-Plate round anchor (GV): from € 595
  - G-Plate square anchor (GV): from € 685
  - Security sleeve deck mount (DECKMNT): from € 230
  - Flush mount for concrete, soil or sand (SSFMC): € 800
  - Stainless steel flush mount for existing concrete (FLUSHMT): € 530
  - Aluminium sand anchor (SANDANCHOR): € 150
  - Second rope hook (ROPEHOOK): € 85
  - Aluminium extension sleeve with hitch pin (EXTPOLE): € 100
  - Stainless steel extension sleeve with hitch pin (SSEXTPOLE): € 340
  - Stainless steel M1 center post for pools (SSCPMAST): € 680
  - Stainless steel pool flush mount with stainless extension (FLUSHMTSS): € 960
  - Stainless steel pool flush mount with containment cup (FLUSHMTSSCUP): € 1,650
  - Grounding lug (GROUNDINGLUG): € 40
- replacement canopy:
  - Replacement canopy for Ocean Master M1 center post: from € 755

Extras on request
longer mast (10, 20 or 30 cm): € 125
M1 PLUS mast Ø 51 mm: € 95 (included on the Auto-Scope sizes), needs a 51 mm stainless steel security sleeve (upcharge € 70)
contrasting binding on the canopy: € 115
15 cm accent border on the canopy: € 250
15 cm cord fringe: € 545
logo printing on the canopy: project set up from € 535 (1 colour, logo up to 90 cm), printing from € 35 per canopy panel, conversion of the logo to vector artwork € 260
canopy cleaning: € 25/m², net price, shipping not included
your own fabric or a fabric outside the Tuuci range (COM): € 175 per fabric and order, net price
Prices exclude VAT.

Ocean Master M1 Zero Horizon
The Zero Horizon is a minimalist take on the parasol. The canopy has a "zero" vertical profile, so it gives you a lot of shade and hardly blocks your view of the nature around you. The canopy has a market cut profile.

You can choose from 4 squares from 200 x 200 to 290 x 290 cm and 4 octagons from R 245 to R 370 cm. All sizes have the Auto-LOC marine pulley lift, two are also available with the EasyDrive crank lift.
