Egoe LEVA green roof, larch
The green roof carries pre-grown stonecrop carpets in two powder-coated aluminium tubs, with a suspended ceiling of wooden slats underneath. The layer build-up includes a 30 mm retention board, a 100 g/m2 filter foil and an extensive roof substrate. The roof can only be placed on the all-steel structure.
structure: two powder-coated aluminium tubs with pre-grown green tiles, suspended ceiling of wooden slats
material: pre-grown green tiles, larch slats
structure colour: on request, 22 standard RAL shades
dimensions: 213 x 207 x 8 cm
weight: 400 kg
layer build-up: 30 mm retention board, 100 g/m2 filter foil, extensive roof substrate, pre-grown stonecrop carpet
restriction: the green roof only goes with the all-steel structure
design: Egoé studio
item code: LEV404-M02000
Technical data
- dimensions: 213 x 207 x 8 cm (2130 x 2070 x 80 mm)
- weight: 400 kg
- structure: two powder-coated aluminium tubs with pre-grown green tiles, suspended ceiling of wooden slats
- material: pre-grown green tiles, larch slats
- structure colour: on request, 22 standard RAL shades (RAL 9010, 1013, 1021, 2008, 3020, 3016, 3003, 3012, 5011, 5019, 5024, 6027, 6019, 6010, 6007, 7022, 7006, 7032, 7035, 7016, 9005, 9007)
- layer build-up: 30 mm retention board, 100 g/m2 filter foil, extensive roof substrate, pre-grown stonecrop carpet
- restriction: the green roof only goes with the all-steel structure
- design: Egoé studio
- item code: LEV404-M02000
- made by Egoé, Czech Republic
About the LEVA system
LEVA is a modular system built from a basic cube and accessories. At home it becomes a children's playroom with a climbing wall, a resting corner with a hanging bed, a dining area of several joined cubes or an outdoor kitchen with herb planters. Companies use it for outdoor offices, festival pergolas, exhibition spaces and cinemas. The structural beams are larch or acacia, the steel joints are galvanised and powder coated, and the textiles and outdoor parts resist weather and need little maintenance. The roofs cover a cube and decide how much sun and rain it lets through.
See the whole system in the Egoé LEVA category and the other modules of this group under Roofs.
